Software Testing

Activity: ISP coverage criteria

(no submission)

Purpose:

Understand and practice ISP coverage criteria
Get ready to work on homework assignment and prepare for quiz 2 and the final exam

Instruction:

You may make a copy of a worksheet and complete this activity, or simply type your answers in any text editor.

You may work alone or with at most two other students in this course.

Assume there are multiple IDMs (i.e., characteristics or partitions):

Blocks for characteristic A	A1	A2
Blocks for characteristic B	B1	B2	B3
Blocks for characteristic C	C1	C2

Possible values for the partitions are as follow:

Values for characteristic A	a	b
Values for characteristic B	1	2	3
Values for characteristic C	x	y

Apply All Combination Coverage (ACoC)

Compute the (maximum) number of tests
sample solution
```
#tests = 2 * 3 * 2 = 12
```

Derive test requirements

sample solution

TR = {
(A1,B1,C1), (A1,B1,C2), (A1,B2,C1), (A1,B2,C2), (A1,B3,C1), (A1,B3,C2)
(A2,B1,C1), (A2,B1,C2), (A2,B2,C1), (A2,B2,C2), (A2,B3,C1), (A2,B3,C2)  }

Substitute test input values

sample solution

(a,1,x), (a,1,y), (a,2,x), (a,2,y), (a,3,x), (a,3,y)
(b,1,x), (b,1,y), (b,2,x), (b,2,y), (b,3,x), (b,3,y)

Apply Each Choice Coverage (ECC)
- Compute the (maximum) number of tests
  sample solution
```
#tests = max_#blocks = 3
```
- Derive test requirements
  sample solution
```
TR = { (A1,B1,C1), (A2,B2,C2), (A2,B3,C1) }
```
- Substitute test input values
  sample solution
```
(a,1,x), (b,2,y), (b,3,x)
```

Apply Pair-Wise Coverage (PWC)

Compute the (maximum) number of tests
sample solution
```
#test = 1st_max_#block * 2nd_max_#block = 3 * 2 = 6
```

Derive test requirements

sample solution


TR = { (B1,A1,C1), (B1,A2,C2), (B2,A1,C2), (B2,A2,C1), (B3,A1,C1), (B3,A2,C2) }

Substitute test input values

sample solution

(1,a,x), (1,b,y), (2,a,y), (2,b,x), (3,a,x), (3,b,y)

Apply Base Choice Coverage (BCC)

Compute the (maximum) number of tests

sample solution

#tests = 1(for #base) + ( (2-1) + (3-1) + (2-1) ) = 5

Derive test requirements

sample solution

First, pick a base. Suppose a base is (A2,B1,C1)

Derive the remaining test requirements.
Hold all but one base choice constant,
use each non-base choice in each other characteristic.

A2,B1,C2
A2,B2,C1     A2,B3,C1
A1,B1,C1

Thus, TR = { (A2,B1,C1), (A2,B1,C2), (A2,B2,C1), (A2,B3,C1), (A1,B1,C1) }

Substitute test input values

sample solution

(b,1,x), (b,1,y), (b,2,x), (b,3,x), (a,1,x)

Apply Multiple Base Choice Coverage (MBCC)

Compute the (maximum) number of tests

sample solution

Suppose there are 2 bases: (A2,B1,C1) and (A2,B2,C2)
#tests = #base + ( #base*(2-#base_choiceA) + #base*(3-#base_choiceB) + #base*(2-#base_choiceC) )
       = 2 + ( 2*(2-1) + 2*(3-2) + 2*(2-2) ) = 6

Derive test requirements

sample solution

Hold all but one base choice constant for each base test,
use each non-base choice in each other characteristic.

For base (A2,B1,C1)
A2,B1,--      Cannot replace C characteristic (all block are used as base)
A2,B3,C1      Cannot replace with B2 since it's also a base choice
A1,B1,C1

For base (A2,B2,C2)
A2,B2,--      Cannot replace C characteristic (all block are used as base)
A2,B3,C2      Cannot replace with B1 since it's also a base choice
A1,B2,C2

Thus, TR = { (A2,B1,C1), (A2,B3,C1), (A1,B1,C1),
             (A2,B2,C2), (A2,B3,C2), (A1,B2,C2) }

Substitute test input values

sample solution

(b,1,x), (b,3,x), (a,1,x),
(b,2,y), (b,3,y), (a,2,y)
